| Model | YTO-EX1254 Cabin |
| Engine | YTO LR6M5-23 |
| Air-inlet way | 6-cylinder, water-cooling, naturally aspirated |
| Rated housepower | 125hp (92kW) |
| Engine rated rotation speed | 2300r/min |
| Torque (N.m) | 480 |
| Engine bore x stroke (mm*mm) | 110*135 |
| Compression ratio | 17.1 |
| Fuel consumption | ≤235g/kW·h |
| Fuel tank capacity | 200L |
| Lube oil capacity (Engine) (L) | 21 |
| Coolant capacity (L) | 20 |
| Transmission oil capacity (L) | 60 |
| Air pre cleaner oil capacity (L) | 1 |
| Hydraulic oil capacity (L) | / |
| Travelling speed | 2.0-28.5/4.5-13.5 km/h |
| Gearbox gears | 12F+4R |
| Gearshift type | Engagement sleeve shift |
| Clutch | 13-inch LUK |
| Hydraulic pump flow | 45L/min |
| Hydraulic pump pressure (Mpa) | 20±0.5 |
| Lifting force | ≥4000kg |
| PTO | 540/1000r/min, 6-teeth/21-teeth |
| PTO power output (Kw) | 540 (6splines): 60 / 1000 (2splines): 75 |
| Wheelbase | 2600mm |
| Wheeltread (front/rear) | 1680-2100mm / 1560-2200mm |
| Min. ground clearance | 470mm |
| Min. turning radius | 6.8±0.3m |
| Overall sizes (L*W*H) | 4900*2350*2700mm (with cabin) |
| Net weight | 5800kg (with cabin) |
| Rated traction force | 28KN |
| Tires (front/rear) | 14.9-26/18.4-38 |
| Electronic voltage (V) | 12 |
| Starter motor power (kW) | 4 |
| Alternator (Amps) | 80A |
| Battery type (Ah) | Lead-acid Battery 150ah |
| Fuel tank capacity (L) | Under-laid 200L |
| Brake type | Oil bath, disc type |
| Cabin Features | Fully enclosed cabin with climate control, sound insulation, ergonomic seating, and enhanced visibility |
| Gauge / safeties | Water temperature gauge, turn single lamp, fuel gauge, Brake light indicator, high beam indicator, charging indicator, low beam indicator, hour meter, oil pressure warning indicator, low pressure warning indicator, rear work light indicator, water temperature indicator |
