YTO-X1204 CABIN WHEELED TRACTOR

YTO-X1204 Canopy Wheeled Tractor
Inquiry

YTO-X1204 CABIN WHEELED TRACTOR

Main Characteristics
  • Fully Enclosed Canopy: Comfortable and weather-protected operator environment providing shade and protection for extended operation;
  • YTO Engine and fuel pump: The engine torque reserve reaches 30%, the power is strong, high fuel injection pressure, good atomization performance, sufficient combustion, and low fuel consumption;
  • Second-order inertial force balance device: The vibration amplitude of the engine reduced by nearly 70%, with light vibration and small noise, and improve the stability and reliability of engine;
  • Air prefilter (desert air filter): Automatic dust removal, no need for cleaning, free daily maintenance;
  • Independent double-acting clutch: LUK brand, independent control Driving and PTO;
  • The drivetrain system: adopts Italian technology, with reasonable structure and high transmission efficiency;
  • Brake: Safe and reliable wet disc brake. With double circuit air brake controlling trailer braking;
  • PTO: Power output can reach 540 and 1000r/min, capable of meeting different operational requirements;
  • The structure of mixed hydraulic and transmission oil: Mixed lubricating oil between lifter and gearbox, Good lubrication, and extend the service life of gearbox and lifter;
  • Force-down Lifter: Force the depth in soil of the implements, improve the working efficiency and effect of tractors with implements, and more suitable for poor soil conditions;
  • Hydraulic output: 2-pair of hydraulic outputs with European connector, 3-pair as option;
  • Weight ballasts: With front 6pcs of weight ballasts.
Technical Specifications List — YTO-X1204 Canopy
ModelYTO-X1204 Canopy
EngineYTO LR6M5-23
Air-inlet way6-cylinder, water-cooling, naturally aspirated
Rated housepower120hp (77.2kW)
Engine rated rotation speed2300r/min
Torque (N.m)460
Engine bore x stroke (mm*mm)110*135
Compression ratio17.1
Fuel consumption≤235g/kW·h
Fuel tank capacity180L
Lube oil capacity (Engine) (L)21
Coolant capacity (L)20
Transmission oil capacity (L)60
Air pre cleaner oil capacity (L)1
Hydraulic oil capacity (L)/
Travelling speed1.9-27.5/4.3-13.2 km/h
Gearbox gears12F+4R
Gearshift typeEngagement sleeve shift
Clutch13-inch LUK
Hydraulic pump flow45L/min
Hydraulic pump pressure (Mpa)20±0.5
Lifting force≥3800kg
PTO540/1000r/min, 6-teeth/21-teeth
PTO power output (Kw)540 (6splines): 58 / 1000 (2splines): 72
Wheelbase2550mm
Wheeltread (front/rear)1650-2050mm / 1550-2150mm
Min. ground clearance470mm
Min. turning radius6.5±0.3m
Overall sizes (L*W*H)4800*2350*2700mm (with canopy)
Net weight5500kg (with canopy)
Rated traction force26KN
Tires (front/rear)14.9-26/18.4-38
Electronic voltage (V)12
Starter motor power (kW)4
Alternator (Amps)80A
Battery type (Ah)Lead-acid Battery 150ah
Fuel tank capacity (L)Under-laid 180L
Brake typeOil bath, disc type
Canopy FeaturesFully enclosed canopy with climate control, sound insulation, ergonomic seating, and enhanced visibility
Gauge / safetiesWater temperature gauge, turn single lamp, fuel gauge, Brake light indicator, high beam indicator, charging indicator, low beam indicator, hour meter, oil pressure warning indicator, low pressure warning indicator, rear work light indicator, water temperature indicator

Distributed in Pakistan By:

PAK TRACTOR MANUFACTURING COMPANY

16-KM, Multan Road, Pakka Mile Stop, Shahpur, Lahore.

Phone: 92-42-37512567-8

UAN: 111-787-456

Fax: 92-42-37512569
